Magnetic drive pump routine inspection：
Proper implementation of the magnetic pump daily inspection is one of the work of each pump personnel, through the necessary inspection and maintenance can be more extent to maintain the performance and service life of the pump, taking into account that most of the magnetic pump transport hazardous gas liquid, if you do not do a good job of daily inspection and maintenance, pump components aging or damage without knowing it, there may be hidden danger of media leakage.
On the magnetic pump routine inspection, you can refer to the following implementation standards.
1. Make a regular maintenance plan, and make corresponding records after the maintenance. Generally, routine inspection is carried out every 1000 hours.
2, each time before using the pump to check the smooth operation, the need to manually turn several laps, to ensure that there is no jammed feeling, at the same time to check the tightness of each connection and fasteners.
3. Check whether there is blockage in the pump chamber. Some chemical components may crystallize after the loss of flow after transportation.
4. For the magnetic pump installed for the first time, it is necessary to check whether the pipeline is independently supported, not to directly place the pipeline on the pump body, and try to keep the horizontal installation, if the working environment can not meet, only vertical installation, then the motor should be kept upward.
5, in the operation process, to check whether the operation parameters are in line with the pump type standard, if the flow is not up to standard, in addition to checking the pump itself, but also to consider whether the medium proportion is too high, or motor failure. In addition, it is also necessary to pay attention to the voltage and current of the motor.
6. Open the pump body every 1000 hours to check the internal components, mainly to check the aging and wear of bearing and end face moving ring and other vulnerable parts, whether the clearance is abnormal, and other moving components should also be checked according to this.
Daily inspection of magnetic pump is the above related matters, according to the pump type specifications have certain differences, if you want to prolong the performance of the pump, the key is to select the model at the beginning of the selection for the actual transportation needs to match the model, such as the transportation of high temperature liquid stainless steel pump type, transportation of high concentration of acid and corrosive liquid is the selection of fluorine plastic magnetic pump and so on, Any questions about pumps can be directed to saiken Pumps.
