What is the pressure of the vertical pipeline pump
2021/05/27 14:57:41
The pressure of the water pump can determine the flow output, which is one of the important performance indicators. Recently, some users are concerned about the pressure of the vertical pipeline pump. For this, the specific model specifications need to be considered. The SAIKEN pump industry makes the common pipeline pump. For related introduction, please refer to the following content for details.
Regarding the pressure of the vertical pipeline pump, take the common ISG vertical pipeline pump as an example, the suction pressure is ≤1.0MPa, the working pressure of the pump system is ≤1.6MPa, that is, the suction port pressure + pump head ≤1.6MPa, and the pump is static. The pressure test pressure is 2.5MPa. When selecting the type, the user needs to clarify the working pressure of the system in advance. If there is a demand for pressure greater than 1.6MPa, you can contact the manufacturer to facilitate the use of cast steel materials for the flow and connection parts of the pump when making the pump.
After understanding the pressure of the vertical pipeline pump, you can further understand the working characteristics and basic performance parameters of the pipeline pump to facilitate the matching of models for transportation projects. The inlet and outlet of vertical structure pipeline pumps are often located on the same centerline and have the same caliber. They can be directly placed in the pipeline during installation, which is not only convenient and beautiful, but also effective in saving building space. In terms of performance parameters, the ISG pipeline pump has an optional caliber range of 15-500mm, a high flow rate of 1450m3/h, and a head range of 7-150m.
In addition to conventional models, pipeline pumps are highly popular water transport equipment in urban water service systems. Nowadays, there are more structures such as hot water, high temperature, chemical, and oil pumps, with different component structures and heat resistance. The chemical pipeline pump can also meet a variety of industrial transportation needs. Users who have customized pipeline pump requirements can contact us by email.
